製品詳細
起源の場所: 中国
ブランド名: E-link
証明: ROHS,FCC,CE
モデル番号: LNK-PJ202 LNK-PJ202AT LNK-PJ302 LNK-PJ302AT
支払いと送料の条件
最小注文数量: 1 PCS
価格: 交渉可能
パッケージの詳細: インジェクター標準エクスポートパッケージ
受渡し時間: 3-12営業日
支払条件: L/C,T/T,ウェスタンユニオン,マネーグラム,Paypal
供給の能力: 1000個/月
キーワード: |
POEアダプターインジェクタ |
動作温度: |
-15℃～+45℃（5℉～113℉） |
寸法 (W x D x H): |
5.79 x 2.28 x 1.57インチ (147×58×40mm) |
電圧範囲: |
AC 100～240V 50/60Hz |
重量: |
200gについて |
キーワード: |
POEアダプターインジェクタ |
動作温度: |
-15℃～+45℃（5℉～113℉） |
寸法 (W x D x H): |
5.79 x 2.28 x 1.57インチ (147×58×40mm) |
電圧範囲: |
AC 100～240V 50/60Hz |
重量: |
200gについて |
► Transfer the data and power through the existing network, plug-and-play
► Conforms the IEEE 802.3at standard
► 100M or 1000M transmission rate to meet the high-bandwidth network applications
► Up to 30W of power on 2-pairs
► Auto-detect of PoE( IEEE 802.at/af) equipment;
► The input terminal of the AC voltage or DC power supply mode can be selected
► Use PD and PSE power supply equipment together,they can provide both data and
► Power for those not support PoE network equipment
► PD output is 5V/9V/12V etc. voltage (choose one)
PoE (Power over Ethernet) is a technology where both data and electricity are transferred via Ethernet cable. A complete PoE system consists of power sourcing equipment (PSE) and powered device (PD). PoE uses two idle ones of four twisted pairs to transfer electricity to connect to Internet along with Ethernet, without additional cabling, providing an effective solution to power supply for deployment of IP network and WLAN wireless broadband equipment in rigorous network environment where power wiring is difficult. It is applicable for centralized power supply used for IP monitoring, wireless access and other applications.
|
Standard |
IEEE 802.3af, IEEE 802.3at |
|
Transfer Data |
10/100M or 10/100/1000Mbps |
|
transmission medium |
10 Base-T: Cat3, 4, 5 UTP, ≤100m |
|
output voltage |
DC 48V; Two Groups 0.6A,Single Port≤30W |
|
Interface |
RJ45 |
|
|
power plug: according to requirement |
|
indicator |
Power and Two Data+Power indicator |
|
voltage range |
AC 100～240V 50/60Hz |
|
power dissipation |
Standby 2.8W; FL 60W |
|
Dimensions (W X D X H) |
5.79 x 2.28x 1.57 in.(147×58×40mm) (Mounting holes on the other gauge) |
|
Weight |
About 200g |
|
Environment |
Operating Temperature: -15℃～+45℃(5℉~113℉) |
|
|
Operating Humidity: 20% ～85％ |
|
|
Storage Temperature -25°C—60°C(-13℉~140℉) |
|
|
Storage Humidity:20% ～90％ |
|
Model |
Decription |
|
LNK-PJ202 |
2-Port PoE Adapter, 10/100Mbps, IEEE 802.3af 15.4W |
|
LNK-PJ202AT |
|
|
LNK-PJ302 |
2-Port PoE Adapter, 10/100/1000Mbps, IEEE 802.3af 15.4W |
|
LNK-PJ302AT |
2-Port PoE Adapter, 10/100/1000Mbps, IEEE 802.3at 30W |
