Product Overview

The LNK-MDF100 Series Mini-type DVI Fiber Optic Extender delivers reliable long-distance transmission of high-resolution digital video signals through a single fiber optic cable. Fully compliant with DVI 1.0 standards, this compact extender supports resolutions up to 1920x1200@60Hz (WUXGA), ensuring crisp and stable image quality over extended distances.

Engineered for superior performance, the system converts electrical DVI signals to optical signals, eliminating susceptibility to electromagnetic interference (EMI) and radio frequency interference (RFI). This guarantees exceptional signal integrity and security, making it ideal for sensitive applications.

The extender features an external stereo audio interface, providing flexible connectivity for integrated audio-video systems. Its miniaturized design allows for easy deployment in space-constrained environments while maintaining robust operation.

Ideal for digital signage, control rooms, conference halls, and educational facilities, the LNK-MDF100 offers a cost-effective and secure solution for extending DVI video and audio signals with professional-grade stability and clarity.

Key Features

• Long-Distance AV Transmission

  • Transmits uncompressed DVI video signals and external stereo audio over a single fiber optic cable for distances up to 20km, enabling flexible system layout far beyond copper cable limitations.

• Comprehensive Resolution Compatibility

  • Supports high-resolution displays up to 1920x1200 (WUXGA) @60Hz and 1080p Full HD, with specialized optimization for 1600x1200 @60Hz for professional graphics applications.

• Broad Format & Pixel Rate Support

  • Ensures wide compatibility with a vast range of DTV resolutions (480i to 1080p) and PC resolutions (VGA to UXGA), handling pixel clock rates from 25MHz to 165MHz for versatile source connectivity.

• Advanced Signal Integrity & Protection

  • An intelligent automatic adjustment system actively optimizes the signal in real-time to deliver exceptionally stable, clear, and smooth images without manual intervention.

  • Features a built-in ESD protection circuit to safeguard connected equipment from electrostatic discharge, enhancing system reliability and durability.

• Simplified Installation & Operation

  • Designed for true plug-and-play operation, requiring no software configuration. The system features high auto-negotiation compatibility to automatically synchronize with source and display devices for immediate use.

Application Scenarios

• Industrial Control Rooms: Provides reliable transmission of process control visualizations and monitoring data from equipment to centralized displays up to 20km away, with complete EMI/RFI immunity for operation in electrically noisy environments.

• Digital Signage Networks: Enables cost-effective deployment of high-resolution digital signage content across campuses, transportation hubs, and retail chains through existing fiber optic infrastructure.

• Broadcast & Pro AV Systems: Serves as a critical signal extension solution for transporting studio monitor feeds and presentation graphics with guaranteed signal integrity and ESD protection.

• Educational & Conference Facilities: Supports lecture hall AV systems by extending computer desktop signals (VGA to WUXGA) from instructor stations to remote projectors or displays with synchronized stereo audio.

• Medical Imaging Applications: Facilitates the secure transmission of non-DICOM medical visualizations (e.g., training content, diagnostic support data) to consultation rooms while maintaining image clarity and grayscale accuracy.

Technical Indexes

Ordering information

Application Display
