3G-SDI Fiber Extender with Analog Audio RS422 Ethernet Tally Sync 20km

Model: LNK-3G2V2BA2D1E1T1S

 Product Description & Overview

This advanced 3G-SDI Fiber Extender delivers comprehensive signal integration for professional

broadcast and surveillance applications, supporting bidirectional 3G-SDI video transmission combined

with multiple auxiliary signals through single-mode fiber infrastructure. The system incorporates a

complete signal management solution featuring 1-channel bidirectional 3G-SDI video, 2-channel

backward analog audio, bidirectional RS422 data communication, 100M Ethernet connectivity,

backward tally signaling, and backward analog tri-level sync transmission. The transmitter and

receiver pair operates seamlessly over single-mode optical cables, providing reliable long-distance

signal extension while maintaining broadcast-grade quality standards.

Engineered for superior performance in demanding environments, this fiber extender utilizes advanced

optical technology to ensure pristine video quality and real-time processing capabilities. The integrated

IP interface enhances system scalability and ensures compatibility with modern network infrastructure,

while the comprehensive signal support enables complete remote production control. The fiber optic

transmission technology provides complete immunity to electromagnetic interference, ground loops,

and radio frequency interference, significantly improving system reliability and signal security compared

to traditional coaxial cable systems.

The extender supports flexible transmission distances up to 20 kilometers with optional configurations

extending to 40km, 60km, or 80km ranges, making it suitable for large-scale installations and distributed

production environments. This solution is particularly valuable for live broadcasting applications, sports

venues, distance learning facilities, and high-definition surveillance systems requiring multi-signal transmission

over extended distances. By consolidating multiple signal types through a single fiber connection, the system

reduces cabling complexity while providing robust, interference-free connectivity that surpasses the limitations

of conventional coaxial-based systems, establishing new standards for signal integrity and operational reliability

in professional video transmission applications.

Key Features Bullets

• Multi-Signal Fiber Integration
  Transmits 1 bidirectional 3G-SDI video, 2 backward analog audio, 1 bidirectional RS422, 1 Ethernet, 1 backward tally, and 1 backward tri-level sync over single fiber

• Comprehensive Standard Compatibility
  Supports HD-SDI, SD-SDI, DVB-ASI formats with bandwidth ranging from 19.4Mb/s to 2.97Gb/s

• Advanced Clock Recovery Technology
  SMPTE 424M (2.97Gb/s) compliant clock recovery system ensuring precise signal synchronization

• Multi-Standard Video Processing
  Compatible with SMPTE 424M, 292M, 259M, and 297M standards for 3G-SDI, HD-SDI, SD-SDI, and ASI applications

• Integrated CWDM Optical System
  Built-in CWDM technology with SFP modules for each signal path enabling wavelength division multiplexing

• Intelligent Signal Equalization
  Automatic cable equalization based on detected data rate for optimal signal integrity

• Real-Time System Monitoring
  LED status indicators providing continuous monitoring of critical operational parameters

• Extended Transmission Capability
  Supports transmission distances up to 20km with optional 40/60/80km configurations available

• Professional Broadcast Applications
  Ideal for live broadcasting, HD surveillance systems, and professional video production environments

• Enhanced Signal Security
  Fiber optic transmission providing complete immunity to EMI and RF interference
